Low Vicat PC Plastic Core Sheet For Contactless PC Card Prelam Or INLAY Sheet Production
Production Specification
| 1. Low Vicat PC Plastic Core Sheet For Contactless PC Card Prelam Or INLAY Sheet Introduction |
Low Vicat PC Plastic Core Sheet For Contactless PC Card Prelam Or INLAY Sheet (Model: MCS-PC-INLAY) is specially designed for INLAY sheet production of Contactless or RFID PC Card. It is featuring lower vicat softening point, which can provide good protection on chips inside during the process of laminator grading lamination process. It is known as the high-quality PC sheet for various contactless or RFID PC cards.
Low Vicat PC Plastic Core Sheet For Contactless PC Card Prelam Or INLAY Sheet is specially designed for high end PC card body production. Comparing with other types of plastic core sheets for card body production, it excels in outstanding optical clarity, printability, impact strength and dimensional stability. It is widely used in such cards as anti-fake IC cards, driving license card, transportation card and passport etc.
| 2. Low Vicat PC Plastic Core Sheet For Contactless PC Card Prelam Or INLAY Sheet Specification |
Low Vicat PC Plastic Core Sheet For Contactless PC Card Prelam Or INLAY Sheet is known as the new reliable material for PC card body production. It has such features as high vicat point and can be used for laser engraving. The PC sheet is perfect for making ID card, E-Passport etc.
Features as below:
1. Excellent strength and wear-resisting
2. High temperature and low temperate resistance;
3. Perfect application for laser Engraving
4. Non-toxic, environment-friendly material
5. Vivid color and high resolution photo quality.
6. Longer service life
| Item | Unit | Value | |
| Density | g/cm3 | 1.30 ±0.05 | |
| Tensile Strength | Horizontal | MPa | ≥50 |
| Vertical | ≥50 | ||
| Vicat | ℃ | 85-90 | |
| Surface Dyne | dynes/cm | ≥38 | |
| Thickness range | mm | 0.05-1.0mm | |
Product details :
Low Vicat PC Plastic Core Sheet For Contactless PC Card Prelam Or INLAY Sheet which is for PC card production , this material has under mentioned advantages :
1. Excellent strength and wear-resisting.
2. High temperature and low temperate resistance.
3. Perfect application for laser engraving.
4. Environment-friendly material.
5. Longer service life.
6. Perfect image of laser etching technology support, apply to
identity cards with anti-fake requirements.
Parameters :
1. Size: 210*297mm ( A4 ) , 310*480mm ( A3 ) or as per customer requirements
2. Thickness: 0.10mm to 0.80mm
3. Color : White
4. Package method : 100 or 200 sheets per bag, 10 bags per paper carton, and the cartons are piled up and firmly fixed on solid plywood pallets
5. Storage condition : Sealed, moisture-proof, room temperature under 40℃
| Product name | Low Vicat PC Plastic Core Sheet For Contactless PC Card Prelam Or INLAY Sheet Production |
| Color | White |
| Thickness Range | 0.05-1.0 mm |
| Vicat point ℃ | 145±2 |
| Tensile strength | ≥50 Mpa |
| Surface | Matte on both sides |
| Density | 1.3 |
| Transparency | ≤5 |
| Heat shrink | ≤0.5 |
| Surface roughness | ＜1.5 |
| Surface tension dynes/cm | ≥38 |
| Glue coated | Without coating on both sides |
| Storage | Sealed, moisture-proof, room temperature under 40℃ |
| 3. Application of Low Vicat PC Plastic Core Sheet For Contactless PC Card Prelam Or INLAY Sheet |
It is widely used in such cards as anti-fake IC cards, driving license card, transportation card and passport etc.
| 4. Packing of Low Vicat PC Plastic Core Sheet For Contactless PC Card Prelam Or INLAY Sheet |
In standard export carton and are packed on plywood pallet
|
|
