High Stickness Glue Coating PVC Coated Overlay for Digital Print used in Smart Card Production
1. High Stickness Glue Coating PVC Coated Overlay for Digital Print used in Smart Card Production - Brief Introduction
High Stickness Glue coating PVC Coated Overlay for Digital Print is developed specially for Inkjet printer Ink. It’s suitable for laminating with the sheets which printed by whole series of Digital presses. It provides excellent peel strength and no deformation or color change after lamination.
Technical Parameters:
| Item | Parameters | |
| Vicat (℃) | 72±2 ℃ | |
| Shrinkage (%) | ≤10% | |
| Tensile Strength (MPa) | MD | ≥40 |
| TD | ≥35 | |
| Roughness (μm) | Ra | 0.5~1.8 |
| Rz | 3~9 | |
| Thickness (mm) | 0.04~0.1 | |
2. High Stickness Glue Coating PVC Coated Overlay for Digital Print used in Smart Card Production - Using Method
Specific to the new coated overlay of HP Indigo electronic ink, suitable for all series of HP Indigo digital printer, it has high peel strength with electronic ink, small lamination discoloration, not easy to cause deformation, and wide application.
Detailed Product Description
1).Thickness Range: 0.04-0.1MM
2).Finish: Matt with glue on one side
3).Size: Customized Roll size or Sheet size
4).High initial stick
Laminate with Inkjet printed sheet directly.
3. High Stickness Glue Coating PVC Coated Overlay for Digital Print used in Smart Card Production- Characteristics
● Suitable for lamination with digital printer Ink, with excellent peel strength.
● Abrasion resistant , prolong the life of cards.
● Environment friendly in the card making process, no solvent or gas discharges.
4.High Stickness Glue Coating PVC Coated Overlay for Digital Print used in Smart Card Production - Technical Parameters
| Item | Parameters | |
| Surface | Clean and flatness | |
| Dimensional Tolerance (mm) | ±1 | |
| Angle Cut Tolerance (mm) | ±1 | |
| Diagonal Difference (mm) | ≤1 | |
| Thickness Tolerance (mm) | ±10% | |
| Vicat (℃) | 72±2 | |
| Shrinkage | MD | ≥ - 40% |
| TD | ≤15% | |
| Tensile Strength (MPa) | MD | ≥35 |
| TD | ≥35 | |
5. High Stickness Glue Coating PVC Coated Overlay for Digital Print used in Smart Card Production - Laminating Condition
| Laminating Unit | Temp(℃) | Pressure(MPa) | Time (min) |
| Heat Laminating | 110~130 | ≥8 | 20 |
| Cool Laminating | ≤20 | ≥8 | 20 |
6.High Stickness Glue Coating PVC Coated Overlay for Digital Print used in Smart Card Production- Packing:
Outer:Carton Inner:PE bag
7.High Stickness Glue Coating PVC Coated Overlay for Digital Print used in Smart Card Production - Storage
Keep package sealed and moisture-proof, room temperature between 5~30℃.
Keep horizontally, avoid oppress heavily and direct sun light.
Stacking height should not exceed one meter.
Shelf life: One year.
|
|
