A3 Magnetic Stripe Coated Overlay Card 0.10mm Adhesion PVC Sheet For Magnetic Strip Card
1. Introduction of A3 Magnetic Stripe Coated Overlay Card 0.10mm Adhesion PVC Sheet For Magnetic Strip Card
A3 PVC Magnetic Stripes Coated Overlay Sheet is used as an outer layer on the printed PVC sheets in card lamination. It simplifies the card making process and provides high bonding strength. It efficiently prevents the cards from scratching or cracking , and cuts down the waste rate in production.
Using method: cover the printed plastic sheets and then laminate together.
It is applied with standard magnetic stripe. It applies the high-quality magnetic stripe made by LUCKY China. It can be directly laminated with the printing sheets in the card laminator before punched into standard magnetic card. It features high adhesion, no color change and deformation with long aging life after the process of lamination.
Steps to make cards:
1. Put printing core and two overlays together , then put into the laminator . ( the laminating temperature and time is determined as per the instruction of the machine ) . Please be noticed that all glue sides of both PVC sheets and Overlays are put inward .
2. Tlamination lasts 10-15 minutes . The pressure is 6-8Mpa. The temperature is 120-140°C.
3. Cutting the card.
| 1 | Magnetic stripe | LOCO, standard width 12.7mm, black color, Peelable transfer model. |
| 2 | Size tolerance | +/-0.5 mm in length and width, +/-5% in thickness. |
| 3 | Overlay thickness | 0.04,0.05,0.06,0.08,0.10mm |
| 4 | Package method | 100/200 sheets per bag or as per customer requirements |
2. Specification of A3 Magnetic Stripe Coated Overlay Card 0.10mm Adhesion PVC Sheet For Magnetic Strip Card
Thickness of overlay: 40-100 Micron
Size: Sheet size or Roll size
Classify: HI_CO 2750OE, LO_CO 300OE
Overlay Type: Coated Overlay, Uncoated Overlay
Magnetic stripe: Lucky or customized.
Technical note: In manufacturing process, it can be directly laminated with PVC printing sheet, simplify the fabrication process, save time, adhesive strength is high.
Specifications:
| Product name | A3 Magnetic Stripe Coated Overlay Card 0.10mm Adhesion PVC Sheet For Magnetic Strip Card |
| Common size | A4, 210x297mm (A3, customized ) |
| Thickness | 0.04mm -1.0 mm |
| Appearance | transparent |
| Coated | glue on back |
| Laminating temperature | 110-150℃ |
| Storage | -10~35℃, sealed, moisture-proof |
| Shelf life | 2 years |
| Packing method | 100pcs/bag, 4000pcs/carton |
1). Size: in sheet, A4, A3 or as per customer requirements
2). Coated overlay thickness range in mm: 0.04,0.05,0.06,0.08,0.10
3).Magnetic stripe feature: LOCO 300oe, standard width 12.7mm, black color, Peelable transfer model, Brand: LUCKY
4). Size tolerance: +/-0.5 mm in length and width, +/-5% in thickness.
5).Package method: 100/200 sheets per bag or as per customer requirements.
6). Storage condition: Sealed, moisture-proof, room temperature under 40℃, Keep it horizontally, avoid heavy pressing and direct sunlight.
3. Application of A3 Magnetic Stripe Coated Overlay Card 0.10mm Adhesion PVC Sheet For Magnetic Strip Card
4. Packing of A3 Magnetic Stripe Coated Overlay Card 0.10mm Adhesion PVC Sheet For Magnetic Strip Card
In standard export carton and packed in plywood pallet
|
|
